Gokul PP Diaphragm Flange End Valve 1.5"

690 INR/Number

Get a Price/Quote

Product Details:

Pressure Medium Pressure
Color White
Product Type PP Diaphragm Valve Flange End
Size 1.5"-40mm
Structure Ball
Channels Intentional & Domestic Market
Caliber Gokul Poly Valves Pvt Ltd
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Gokul PP Diaphragm Flange End Valve 1.5" Price And Quantity

Minimum Order Quantity 10 Number
Price 690 INR/Number
Price Range 690.00 - 690.00 INR/Number

Gokul PP Diaphragm Flange End Valve 1.5" Product Specifications

Application industrial and water application
Product Type PP Diaphragm Valve Flange End
Color White
Temperature of Media 80 Celsius (oC)
Pressure Medium Pressure
Flange 150 class
Size 1.5"-40mm
Port Size 1.5"-40mm
Material Plastic
Channels Intentional & Domestic Market
Structure Ball
Media Water
Usage Industrial & Water Application
Connection Flanged
Caliber Gokul Poly Valves Pvt Ltd
Finish Polypropylene (PP)

Gokul PP Diaphragm Flange End Valve 1.5" Trade Information

FOB Port Ahmedabad
Payment Terms Cash Advance (CA) Cash in Advance (CID) Cheque
Supply Ability 10 Number Per Day
Delivery Time 1 Days
Sample Available Yes
Sample Policy Contact us for information regarding our sample policy
Packaging Details Box Packing
Main Export Market(s) Middle East Africa Asia Australia Central America North America South America Eastern Europe Western Europe
Main Domestic Market All India
Certifications ISO & Material Test Certificate

Product Description

Technical Specification

Material Of Construction	PP (Polypropylene)	Construction	weir type design,Soft seated, raising stem
Design	2 Piece Design	Connection End	Flanged as per ANSI B 16.5 (150#) & BS 10 (Table D/E/F) & DIN STD.
Size Range	15MM to 150MM	Test pressure	6 kg./cm2
Max working temp	70 c (consistently)	Standard	As per manufacturer

Material Specification

No.	DESCRIPTION	MATERIAL	QTY.
1)	Body	Polypropylene	1
2)	Bonnet	Polypropylene	1
3)	Hand wheel	Polypropylene	1
4)	Diaphragm	Neoprene Rubber	1
5)	Compressor	PP	1
6)	Stem / Spindel	M.S. /Brass	1
7)	Nut	M.S./ S.S.	1
8)	Pin	M.S./ S.S.	1
9)	Bolt, Nut, Washer	M.S./ S.S.	REQ
10)	Cap	Polypropylene	1
